Slamtec
RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone
RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone
Couldn't load pickup availability
Dimension and Weight
Height: 41.3mm Weight: 110g Size: 55.6 x 55.6 x 41.3mm
Measurement Performance
| Applications Scenarios | Robot Vacuum Cleaner, Hobbyist/Educational Application, Commercial Robot |
| Distance Range | White: 0.05~12m (70% Reflectivity) |
| Black: 0.05~6m (10% Reflectivity) | |
| Sample Rate | 5KHz |
| Sample Frequency | 8~12Hz, 10Hz (Typical) |
| Angle Resolution | 0.72° |
| Pitch Angle | 0°-1.5° |
| Communication Interface | TTL UART |
| Communication Speed | 460800 |
| Ranging Resolution | ±30mm |
| Range Accuracy | 15mm |
| Proof Level | IP54 |
| Anti-Ambient Light Ability | 40,000lux |
✅ Traceable Supply Chain — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)
This product is supplied through a traceable supply chain. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.
Why Buy From Ai-Paipai?
- Genuine & Traceable — sourced through a verifiable supply chain.
- Local Engineering Support — datasheets, SDKs, and pre-flashed images in English and Chinese.
- OEM / ODM & FPGA Customization — tailor specs, enclosures, and BSP for your project.
- One-Stop Sourcing — Firefly + youyeetoo + our own FPGA / edge lineup in one store.
Frequently asked questions
What is RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone used for?
RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone is a Embedded Computing from Slamtec. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.
Does RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item through a traceable supply chain and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.
Can I order RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.
How is RPLidar C1 - 360° 12Meter Lidar Scanner - Seamless switching of A1M8 - DTOF Lidar Sensor UAV Drone shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.
Specifications
| Applications Scenarios | Robot Vacuum Cleaner, Hobbyist/Educational Application, Commercial Robot |
| Distance Range | White: 0.05~12m (70% Reflectivity) |
| Sample Rate | 5KHz |
| Sample Frequency | 8~12Hz, 10Hz (Typical) |
| Angle Resolution | 0.72° |
| Pitch Angle | 0°-1.5° |
| Communication Interface | TTL UART |
| Communication Speed | 460800 |
| Ranging Resolution | ±30mm |
| Range Accuracy | 15mm |
| Proof Level | IP54 |
| Anti-Ambient Light Ability | 40,000lux |
