PZ9643 Dual Channel ADC Board AD9643 14bit 250MSPS FMC Interface 120P Expansion Industrial Grade Data Acquisition Module

PZ9643 Dual Channel ADC Board AD9643 14bit 250MSPS FMC Interface 120P Expansion Industrial Grade Data Acquisition Module

$259.00 USD
$259.00 USD
Sale Sold out
Shipping calculated at checkout.

PZ9643 Dual Channel ADC Board AD9643 14bit 250MSPS FMC Interface 120P Expansion Industrial Grade Data Acquisition Module

  • High-Speed Data Acquisition:Equipped with Analog Devices AD9643 ADC chip, offering 14-bit resolution and 250MSPS maximum sampling rate for accurate high-speed signal digitization.
  • Dual-Channel Synchronous Sampling:Supports two independent input channels, ideal for applications requiring synchronized analog-to-digital conversion.
  • Industrial-Grade Design:Operates reliably from -40°C to +85°C, meeting stringent industrial requirements for harsh environments.
  • FMC Interface Power Supply:Powered directly from the FMC interface (12V), ensuring seamless integration with FPGA carrier boards and low-noise performance.
  • Flexible Expansion & Integration:Features a 120P expansion port for signal routing or additional interface customization, supporting modular system design.

The PZ9643 is a high-performance ADC daughter board designed for industrial-grade data acquisition systems. It features the AD9643 chip from Analog Devices, offering dual-channel 14-bit resolution and up to 250MSPS sampling rate. With a robust temperature tolerance from -40°C to +85°C, it is ideal for field-deployable systems. The board supports FMC interface power supply (12V) and provides a 120P expansion port for further flexibility. This module is suitable for integration with FPGA platforms in applications like radar, SDR, instrumentation, and high-speed data logging.

ALINX (FPGA China) is a leading Chinese designer and manufacturer of Xilinx / AMD FPGA development boards, Zynq SoM core boards, SDR and high-speed IO modules — engineered for embedded, industrial, SDR, video and AI edge applications.

Specifications follow the manufacturer listing. Contact us for datasheets, carrier-board reference designs or volume / OEM pricing.
