PZ-ECAT58100 EtherCAT Slave Board FPGA Module Supports Xilinx FPGA AXI4 Lite Interface Dual RJ45 Port for Industrial Automation

PZ-ECAT58100 EtherCAT Slave Board FPGA Module Supports Xilinx FPGA AXI4 Lite Interface Dual RJ45 Port for Industrial Automation

$299.00 USD
$299.00 USD
Sale Sold out
Shipping calculated at checkout.

PZ-ECAT58100 EtherCAT Slave Board FPGA Module Supports Xilinx FPGA AXI4 Lite Interface Dual RJ45 Port for Industrial Automation

  • High Compatibility with Xilinx FPGAs:Compatible with Zynq-7000, Kintex-7, and other Xilinx series via AXI4-Lite interface, enabling seamless EtherCAT integration into your FPGA design.
  • Industrial-Grade EtherCAT Slave Support:Supports up to 100Mbps full-duplex transmission, dual RJ45 ports with automatic crossover, and robust communication performance for real-time control.
  • Compact and Stackable Design:Compact 3.5x2.8 inch form factor ideal for integration into system-level solutions; plug-and-play with headers and included demo source code.
  • Complete Development Resources Included:Board comes with full demo project files (Vivado-based), including documentation, Bitstream, driver, and testbench for fast deployment.
  • Ideal for Industrial and AI Applications:Designed for factory automation, robotic systems, image processing, and industrial AI where real-time Ethernet communication is essential.

The PZ-ECAT58100 EtherCAT Slave Board is a high-performance FPGA module designed for industrial applications requiring reliable and deterministic communication. It supports standard AXI4-Lite interfaces for seamless integration with Xilinx FPGAs such as Zynq-7000 and Kintex-7. Featuring dual RJ45 ports with 100M full-duplex EtherCAT support, this module is ideal for real-time motion control, machine vision, robotics, and AI-edge platforms. This board comes with comprehensive development resources including Vivado project files, hardware drivers, test code, and full documentation. With its compact 3.5 x 2.8 inch layout and plug-and-play design, it is suitable for direct deployment in embedded systems and offers out-of-the-box EtherCAT demo support.
