Puzhi FPGA PZ7010S-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx

Puzhi FPGA PZ7010S-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx

$129.99 USD
$129.99 USD
Sale Sold out
Shipping calculated at checkout.

The Puzhi FPGA is a system-on-module (SoM) based on the XC7Z010.

Typical use cases: industrial control, SDR and rapid prototyping. Supplied by Ai-Paipai with local engineering support, SDK / image pre-flashing and OEM / ODM options; ships worldwide.

Specifications

Brand Puzhi

Product Details

eBay Puzhi FPGA ZYNQ7000 ZYNQ7010S Core Board XC7Z010-2CLG400I 5V/1A Speed Grade 2

Main Features:

- ZYNQ core board,dual-core ARM Cortex-A9,main frequency 667Mhz

- 512MB DDR3,256Mb QSPIFLASH

- Small size 60mm*45mm,up to 122 IO available

- Extreme material selection and process standards,industrial grade -40℃~+85℃

- Support PYNQ,provide hardware reference & rich routines,help product development

FPGA Core Board  PZ7010S-SOM

FPGA Chip XC7Z010-2CLG400I

Processor Core Dual Core ARM Cortex-A9

Speed Grade 2

Chip Level Industrial Grade (-40°C~+85°C)

Logic Cells 28K

Lookup Tables 17600

Flip-Flops 35200

DSP Slices 80

BLOCK RAM 2.1Mb

DDR3/DD3L 512MB

QSPI FLASH 256Mb

PS Side MIO 30 PS ports (24 fixed 1.8V, 6 fixed 3.3V)

PL Side IO 92 Single-ended IOs(1.8/2.5/3.3V adjustable, default 3.3V)

Gigabit Ethernet 1

User LED 2

Voltage / Current 5V/1A

Crystal Oscillator Single-ended Crystal 33.3333MHz for PS
