Puzhi

Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx

Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx

$129.99 USD
$129.99 USD
Sale Sold out
Shipping calculated at checkout.

Built for embedded deployment, the Puzhi FPGA system-on-module (SoM) pairs a XC7Z010 with a practical I/O set.

Typical use cases: industrial control, SDR and rapid prototyping. Supplied by Ai-Paipai with local engineering support, SDK / image pre-flashing and OEM / ODM options; ships worldwide.

Specifications

Brand Puzhi

Product Details

eBay Puzhi FPGA ZYNQ7000 ZYNQ7010 Core Board XC7Z010-2CLG400I Dual Core ARM Cortex-A9

Main Features:

- ZYNQ core board,dual-core ARM Cortex-A9,main frequency 667Mhz

- 512MB DDR3,4GB EMMC,128Mb QSPIFLASH

- Small size 61mm*61mm,up to 118 IO available,no components on the back

- Extreme material selection and process standards,industrial grade -40℃~+85℃

- Support PYNQ,provide hardware reference & rich routines,help product development

FPGA Core Board PZ7010-SOM

FPGA Chip XC7Z010-2CLG400I

Processor Core Dual Core ARM Cortex-A9

Speed Grade 2

Chip Level Industrial Grade (-40°C~+85°C)

Logic Cells 28K

Lookup Tables 17600

Flip-Flops 35200

DSP Slices 80

BLOCK RAM 2.1Mb

DDR3 512MB

QSPI FLASH 128Mb

EMMC 4GB

PS Side MIO 24

PL Side IO Total 94 Single-ended IOs

of which, 46 IOs fixed at 3.3V,48 IOs 1.8/2.5/3.3V adjustable,default 3.3V

Start-up Mode JTAG/QSPI/SD, On-board DIP Switch Selection

Gigabit Ethernet 1

View full details

Not sure which platform fits your project?

Frequently asked questions

What is Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx used for?
Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx is a Xilinx FPGA SoM from Puzhi. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.

Does Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item through a traceable supply chain and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.

Can I order Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.

How is Puzhi FPGA PZ7010-SOM Core Board XC7Z010 ZYNQ 7000 Development Board Xilinx shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.
