• Firefly CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment
  • Firefly CSB1-N10R3588 — view 2
  • Firefly CSB1-N10R3588 — view 3
  • Firefly CSB1-N10R3588 — view 4
  • Firefly CSB1-N10R3588 — view 5
1 5

Firefly

CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment

CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment

$8,919.00 USD
$8,919.00 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment is a Firefly product sold by Ai-Paipai. Key specifications — Soc: RK3588 · Ai computing power: 60TOPS (INT8) · Storage: 256GB eMMC × 10 (Number of compute nodes)(Optional:… · Display: 1 × VGA (maximum resolution 1080P, BMC management display) · Storage expansion: 3.5-inch/2.5-inch SATA3.0/SSD hard drive slot × 1 (BMC…. Typical applications: edge AI inference, machine vision and IoT gateway deployments. Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.) is an authorized distributor providing local technical support, pre-installed SDK / OS images, OEM / ODM customization, and worldwide shipping.

✅ Authorized Distributor — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)

This product is supplied by an authorized distributor of the original brand. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.

The CSB1-N10R3588 Server delivers 60 TOPS computing power for AI workloads, enabling private deployment of large models with secure, high-speed networking and multi-framework support for deep learning. Ideal for scalable, enterprise-ready AI solutions.

Feature

  • Octa-core AI Processor RK3588: The CSB1-N10R3588 system can accommodate up to 10 computing nodes, each of which is equipped with a Rockchip R3588 processor with a maximum frequency of 2.4GHz, with a total computing power of up to 60TOPS.
  • Custom Private Deployment of AI Models: Supports private deployment of rich parameter models based on the Transformer framework, including Gemma-2B, ChatGLM3-6B, Qwen1.5-1.8B, Phi-3-3.8B, and many other language models.
  • Equipped with aBMC Management System: Cooperating with the BMC remote management system, it can easily realize real-time monitoring, software configuration, hardware management, remote operation and maintenance, and provide secondary development capabilities.
  • Effectively Reduce Costs: The server integrates computing modules, storage, USB interfaces, network controllers, power management and sensors into a streamlined system, minimizing users' procurement, development and operating expenses.

Hardware Overview

Shipping list

  • Main unit × 1
  • Power adapter / cable (region plug on request) × 1
  • Accessories vary by configuration — contact us for the exact included list.
Server form
1U rack-mounted computing power server
Number of nodes
10 distributed computing nodes (up to 80 ARM cores) + 1 control node
Compute nodes
Octa-core 64-bit processor RK3588, main frequency up to 2.4GHz
Control nodes
Octa-core 64-bit processor RK3588, main frequency up to 2.4GHz, the highest computing power is 6TOPS
Ai computing power
60TOPS (INT8)
Fan module
6 high-speed cooling fans
Installation requirements
IEC 297 Universal Cabinet Installation: 19 inches wide and 800 mm deep and above Retractable slideway installation: The distance between the front and rear holes of the cabinet is 543.5mm - 848.5mm
Bmc
The BMC management system is integrated with the web-based management interface, supporting Redfish, VNC, NTP, monitoring advanced and virtual media, and the BMC management system can be redeveloped
Large model
Support the privatization deployment of ultra-large-scale parametric models under the Transformer architecture, such as Gemma-2B, ChatGLM3-6B, Qwen-1.8B, Phi-3-3.8B and other large language models
Deep learning
It supports traditional network architectures such as CNN, RNN, and LSTM, and supports the import and export of RKNN models; Support a variety of deep learning frameworks, including TensorFlow, TensorFlow Lite, PyTorch, Caffe, ONNX and Darknet. It also supports the development of custom operators
Console
1 × Console (RJ45, BMC debug serial port, baud rate 115200)
Soc
RK3588
Cpu
Octa-core 2.4GHz
Storage
256GB eMMC × 10 (Number of compute nodes)(Optional: 16GB/32GB/64GB/128GB/256GB)
Storage expansion
3.5-inch/2.5-inch SATA3.0/SSD hard drive slot × 1 (BMC can directly operate the hard drive, and computing child nodes can indirectly access the hard drive through the network sharing method provided by BMC)
Power
550W AC power supply (Input: 90V AC~264V AC, 47 Hz~63 Hz, 8A) (Hot swappable not supported)
Display
1 × VGA (maximum resolution 1080P, BMC management display)
Dimension
420.0mm(L) × 421.3mm(W) × 44.4mm(H)
Weight
Server net weight: 8.1kg, total weight with packaging: 10.3kg
Environment
Operating Temperature: 0ºC ~ 45ºC Storage Temperature: -40ºC ~ 60ºC Operating Humidity: 5% ~ 90%RH(non-condensing)
Internet
2 × 10G Ethernet (SFP+), 2 × Gigabit Ethernet (RJ45), 1 × Gigabit Ethernet (RJ45, MGNT is used as BMC management network)
Usb
2 × USB3.0 (The lower USB is USB3.0 OTG, and the BMC can be upgraded OTG by using a USB flash drive)
Button
1 × Reset, 1 × UID, 1 × Power button
Other
1 × RS232 (DB9, baud rate 115200), 1 × RS485 (DB9, baud rate 115200)
Product tutorials
Click Here
Sdk software and firmware files
Click Here
Product tutorialsClick Here
Product datasheetClick Here
SDK software and firmware filesClick Here

Document links will be replaced with the official Firefly resource URLs on request.

Our cooperating carriers: FedEx, DHL, UPS, SF Express

Delivery Area And Cost

Country/Region 0–2kg 2–3kg 3–4kg 4–5kg 5–6kg 6–7kg 7–8kg 8–9kg 9–10kg
Japan, Taiwan, Hong Kong, Macau $15 $20 $25 $30 $35 $40 $45 $50 $55
Singapore, Thailand, Malaysia $20 $25 $30 $35 $40 $45 $50 $55 $60
Indonesia, Philippines $25 $30 $40 $50 $60 $70 $80 $85 $95
South Korea $25 $35 $35 $45 $45 $55 $55 $65 $65
United States, Australia, New Zealand, Canada, UK, and most of Western Europe $30 $45 $55 $65 $75 $85 $95 $105 $115
Other regions (Eastern Europe, Middle East, Latin America, etc.) $50 $65 $80 $95 $110 $125 $135 $150 $165

Shipping time is for reference only; the actual situation shall prevail.

Why Buy From Ai-Paipai?
  • Authorized & Genuine — sourced directly from brand-approved channels.
  • Local Engineering Support — datasheets, SDKs, and pre-flashed images in English and Chinese.
  • OEM / ODM & FPGA Customization — tailor specs, enclosures, and BSP for your project.
  • One-Stop Sourcing — Firefly + youyeetoo + our own FPGA / edge lineup in one store.
View full details

Frequently asked questions

What is CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment used for?
CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment is a AI Server / Cluster from Firefly. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.

Does CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item as an authorized distributor and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.

Can I order CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.

How is CSB1-N10R3588 1U Server 60T Large Model Privatization Deployment shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.

Specifications

Product Datasheet Click Here
Octa-core AI Processor RK3588 The CSB1-N10R3588 system can accommodate up to 10 computing nodes, each of which is equipped with a Rockchip R3588 processor with a maximum frequency of 2.4GHz, with a total computing power of up to 60TOPS.
Custom Private Deployment of AI Models Supports private deployment of rich parameter models based on the Transformer framework, including Gemma-2B, ChatGLM3-6B, Qwen1.5-1.8B, Phi-3-3.8B, and many other language models.
Equipped with aBMC Management System Cooperating with the BMC remote management system, it can easily realize real-time monitoring, software configuration, hardware management, remote operation and maintenance, and provide secondary development capabilities.
Effectively Reduce Costs The server integrates computing modules, storage, USB interfaces, network controllers, power management and sensors into a streamlined system, minimizing users' procurement, development and operating expenses.
