• Firefly CQ38W-1126B AI Camera
1 1

Firefly

CQ38W-1126B AI Camera Module for Smart Vision – Firefly

CQ38W-1126B AI Camera Module for Smart Vision – Firefly

$189.00 USD
$189.00 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

CQ38W-1126B AI Camera is a Firefly product sold by Ai-Paipai. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping. The CQ38W-1126B AI camera uses the Rockchip RV1126B quad-core AI vision processor, equipped with a 3-top-PS NPU. Typical applications: edge AI inference and machine vision. Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.) is an authorized distributor providing local technical support, pre-installed SDK / OS images, OEM / ODM customization, and worldwide shipping.

✅ Authorized Distributor — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)

This product is supplied by an authorized distributor of the original brand. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.

The CQ38W-1126B AI camera uses the Rockchip RV1126B quad-core AI vision processor, equipped with a 3-top-PS NPU. It supports 12MP encoding and 4K decoding. It features a built-in 12MP ISP / 8MP AI-ISP with low power consumption. The hardware AI mosaic function supports adaptive day/night switching and features 6-axis digital image stabilization and multi-light source fusion. It is equipped with a 5MP high-definition camera and supports an adaptive 100M Ethernet port. It is characterized by low power consumption and high integration.

Feature

  • AI Vision Processor RV1126
  • Supports Multimodal Models
  • Built-in 8-Megapixel AI-ISP
  • AI Video Stabilization & Multi-Light Fusion
  • Intelligent Encoding Engine
  • Optional 5MP / 3MP Cameras
  • Supports Adaptive 100M Ethernet Port
  • IP67-Rated Waterproof Aluminum Alloy Enclosure

Specifications

SoC  Rockchip RV1126B
CPU Quad-core 64-bit ARM Cortex-A53, integrated with NEON and FPU, maximum main frequency of 1.6GHz
NPU 3TOPS NPU, supporting INT4/INT8/INT16/FP16 mixed-precision computing
ISP Built-in 12MP ISP with multiple algorithm accelerators including HDR, 3A, LSC, 3DNR, 2DNR, sharpening, defogging, fisheye correction, gamma correction and feature point detection. Integrated 8MP AI-ISP enables day-night dual-mode adaptation with AI Remosaic technology; supports 6-DOF digital image stabilization.
Decoding/ Encoding Encoding: 12M@30fps H.265/H.264
Decoding: 4K@30fps H.265/H.264
RAM LPDDR4/LPDDR4X (1GB/2GB/4GB Optional)
Storage eMMC (8GB/16GB/64GB Optional)
OS Supports Debian 12 and Linux systems built with Buildroot+QT GUI
Size 69.72mm × 69.72mm × 174.21mm
Power DC 12V (5.5mm × 2.1mm)
Protection rating IP67 waterproof and dustproof design
Weight ≈336g
Environment Operating temperature: -20℃~50℃, Operating humidity: 15%~90%RH (non-condensing)
Image sensor 3MP: SONY SC3336
5MP: SONY IMX335
CMOS size 1/2.8"
Pixel 3-megapixel (2304×1296) / 5-megapixel (2592×1944)
Aperture 3MP: F2.0
5MP: F2.56
Field of view 3MP: 98.3°
5MP: 95°
Focal length 3MP: 3.95mm
5MP: 4mm
Distortion 3MP: < 33%
5MP: ≤ -9.5%
Maximum frame rate 3MP: 2304×1296@30fps
5MP: 2592×1944@30fps
Focusing method 3MP: Manual focus
5MP: Fixed focal length
Camera type Color
Ethernet One 10/100M Ethernet (RJ45)
RS485 1 × RS485 (Led out via 2Pin-3.5mm Phoenix terminal block)

Shipping list

  • Main unit × 1
  • Power adapter / cable (region plug on request) × 1
  • Accessories vary by configuration — contact us for the exact included list.

Detailed specifications are listed on the product images. Contact Ai-Paipai technical support for the full datasheet (PDF) and manufacturer documentation.

Product tutorialsClick Here
Product datasheetClick Here
SDK software and firmware filesClick Here

Document links will be replaced with the official Firefly resource URLs on request.

Our cooperating carriers: FedEx, DHL, UPS, SF Express

Delivery Area And Cost

Country/Region 0–2kg 2–3kg 3–4kg 4–5kg 5–6kg 6–7kg 7–8kg 8–9kg 9–10kg
Japan, Taiwan, Hong Kong, Macau $15 $20 $25 $30 $35 $40 $45 $50 $55
Singapore, Thailand, Malaysia $20 $25 $30 $35 $40 $45 $50 $55 $60
Indonesia, Philippines $25 $30 $40 $50 $60 $70 $80 $85 $95
South Korea $25 $35 $35 $45 $45 $55 $55 $65 $65
United States, Australia, New Zealand, Canada, UK, and most of Western Europe $30 $45 $55 $65 $75 $85 $95 $105 $115
Other regions (Eastern Europe, Middle East, Latin America, etc.) $50 $65 $80 $95 $110 $125 $135 $150 $165

Shipping time is for reference only; the actual situation shall prevail.

Why Buy From Ai-Paipai?
  • Authorized & Genuine — sourced directly from brand-approved channels.
  • Local Engineering Support — datasheets, SDKs, and pre-flashed images in English and Chinese.
  • OEM / ODM & FPGA Customization — tailor specs, enclosures, and BSP for your project.
  • One-Stop Sourcing — Firefly + youyeetoo + our own FPGA / edge lineup in one store.
View full details

Frequently asked questions

What is CQ38W-1126B AI Camera Module for Smart Vision – Firefly used for?
CQ38W-1126B AI Camera Module for Smart Vision – Firefly is a AI Camera from Firefly. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.

Does CQ38W-1126B AI Camera Module for Smart Vision – Firefly include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item as an authorized distributor and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.

Can I order CQ38W-1126B AI Camera Module for Smart Vision – Firefly with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.

How is CQ38W-1126B AI Camera Module for Smart Vision – Firefly shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.

Specifications

SoC Rockchip RV1126B
CPU Quad-core 64-bit ARM Cortex-A53, integrated with NEON and FPU, maximum main frequency of 1.6GHz
NPU 3TOPS NPU, supporting INT4/INT8/INT16/FP16 mixed-precision computing
Decoding/ Encoding Encoding: 12M@30fps H.265/H.264 Decoding: 4K@30fps H.265/H.264
RAM LPDDR4/LPDDR4X (1GB/2GB/4GB Optional)
Storage eMMC (8GB/16GB/64GB Optional)
OS Supports Debian 12 and Linux systems built with Buildroot+QT GUI
Size 69.72mm × 69.72mm × 174.21mm
Power DC 12V (5.5mm × 2.1mm)
Protection rating IP67 waterproof and dustproof design
Weight ≈336g
Environment Operating temperature: -20℃-50℃, Operating humidity: 15%-90%RH (non-condensing)
Image sensor 3MP: SONY SC3336 5MP: SONY IMX335
CMOS size 1/2.8"
Pixel 3-megapixel (2304×1296) / 5-megapixel (2592×1944)
Aperture 3MP: F2.0 5MP: F2.56
Field of view 3MP: 98.3° 5MP: 95°
Focal length 3MP: 3.95mm 5MP: 4mm
Distortion 3MP: < 33% 5MP: ≤ -9.5%
Maximum frame rate 3MP: 2304×1296@30fps 5MP: 2592×1944@30fps
Focusing method 3MP: Manual focus 5MP: Fixed focal length
Camera type Color
Ethernet One 10/100M Ethernet (RJ45)
RS485 1 × RS485 (Led out via 2Pin-3.5mm Phoenix terminal block)
