Core-3588J 8K AI System on Module RK3588 SOC

Core-3588J 8K AI System on Module RK3588 SOC

$289.00 USD
$289.00 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

Core-3588J 8K AI System on Module RK3588 SOC is a Firefly product sold by Ai-Paipai. Key specifications — Soc: RockChip RK3588 · Npu: NPU computing power is up to 6 TOPS, Supports… · Ram: 4GB/8GB/16GB 64bit LPDDR4/LPDDR4x/LPDDR5 (Up to 32GB… · Storage: 16GB/32GB/64GB/128GB eMMC · Network: Integrated with PCIe3.0/GMAC/SDIO3.0/USB3.0, it can be…. Typical applications: edge AI inference, machine vision and industrial automation. Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.) is an authorized distributor providing local technical support, pre-installed SDK / OS images, OEM / ODM customization, and worldwide shipping.

✅ Authorized Distributor — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)

This product is supplied by an authorized distributor of the original brand. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.

The system on module is equipped with Rockchip RK3588 new generation 8-core 64-bit processor and can be configured with up to 32GB RAM. It has 8K video encoding and decoding capabilities, provides rich interfaces, supports multiple hard drives, Gigabit Ethernet, WiFi6, 5G/4G expansion, and rich video input and output interfaces. In addition, it also supports multiple operating systems. The SoM can be widely used in ARM PC, edge computing, cloud servers, smart NVR and other fields.

Feature

  • 8K Video Encoding And Decoding: Supports 8K@60fps H.265/VP9 video decoding and 8K@30fps H.265/H.264 video encoding, and also supports encoding and decoding simultaneously — achieves up to 32-channel 1080P@30fps decoding and 16-channel 1080P@30fps encoding.
  • New-gen AIoT SoC RK3588: RK3588 is Rockchip's new generation flagship AIoT chip, built with 8nm photolithography technology. It is equipped with an 8-core 64-bit CPU with a main frequency of up to 2.4GHz. It integrates ARM Mali-G610 MP4 quad-core GPU, built-in AI acceleration NPU, provides 6Tops computing power, and supports mainstream deep learning frameworks. The powerful RK3588 can show more optimized performance in various AI application scenarios.
  • Multi-channel Input And Output: Equipped with HDMI 2.1/eDP1.3/MIPI-DSI/DP1.4/BT.1120 multi-channel video output and HDMI RX2.0/MIPI-CSI/DVP video input interface, it supports multi-channel 8K video output and 4K video input, and can achieve up to seven screens output and support different displays. It integrates 48MP ISP, supports HDR&3DNR, and supports dual MIPI-CSI camera input.
  • Multiple Hard disks, Massive Capacity: It supports expansion of multiple PCIe3.0/SATA3.0 SSD/HDD mass storage devices at the same time, making it a reality that the device can be easily expanded with TB storage capacity.

Application

  • Edge Computing
  • ARM PC
  • AR/VR
  • Smart Car
  • Cloud Server
  • Smart NVR

Shipping list

  • Main unit × 1
  • Power adapter / cable (region plug on request) × 1
  • Accessories vary by configuration — contact us for the exact included list.
Shipping list
Core-3588J x 1
Soc
RockChip RK3588
Cpu
8-core 64-bit (4 × Cortex-A76+4 × Cortex-A55), 8nm lithography process, frequency up to 2.4GHz
Gpu
ARM Mali-G610 MP4 quad-core GPU Supports OpenGL ES3.2 / OpenCL 2.2 / Vulkan1.1, 450 GFLOPS
Npu
NPU computing power is up to 6 TOPS, Supports INT4/INT8/INT16 mixed operation, Supports framework switching of TensorFlow / MXNet / PyTorch / Caffe / etc.
Vpu
Video decoding: 8K@60fps H.265/VP9/AVS2 8K@30fps H.264 AVC/MVC 4K@60fps AV1 1080P@60fps MPEG-2/-1/VC-1/VP8 Video encoding: 8K@30fps encoding, Supports H.265 / H.264 * Achieves up to 32-channel 1080P@30fps decoding and 16-channel 1080P@30fps encoding
Ram
4GB/8GB/16GB 64bit LPDDR4/LPDDR4x/LPDDR5 (Up to 32GB optional)
Storage
16GB/32GB/64GB/128GB eMMC
Pcie
1 × PCIe3.0 (2×2 lanes/1×4 lanes/4×1Lane/1×2lanes+2×1lane) 3 × PCIe2.1 (1 lane, Multiplexed with SATA3.0)
Sata
3 × SATA3.0 (Multiplexed with PCIe2.1)
Power
4V (voltage tolerance±5%)
Power consumption
Idle: ≈1.35W (12V/110mA) Typical: ≈4.8W (12V/400mA) Max: ≈20W (12V/1700mA)
Video output
2 × HDMI2.1 (8K@60fps or 4K@120fps, Combo with eDP (4K@60fps)) 2 × MIPI-DSI (4K@60fps) 2 × DP1.4 (8K@30fps, Combo with USB 3.0) 1 × BT.1120 (1080P@60fps)
Video input
1 × HDMI-IN (4K@60fps), supports HDCP 2.3 1 × MIPI CSI (4 lanes) or 2×MIPI CSI (2 lanes) 2 × MIPI DC (4-lane DPHY v2.0 or 3-lane CPHY V1.1) 1 × DVP camera (up to 150MHz input data) * Supports multi-channel 8K video output and 4K video input, up to seven-screen output with different displays
Display
Video output: 2 × HDMI2.1 (8K@60fps or 4K@120fps, Combo with eDP (4K@60fps)) 2 × MIPI-DSI (4K@60fps) 2 × DP1.4 (8K@30fps, Combo with USB 3.0) 1 × BT.1120 (1080P@60fps) Video input: 1 × HDMI-IN (4K@60fps), supports HDCP 2.3 1 × MIPI CSI (4 lanes) or 2 × MIPI CSI (2 lanes) 2 × MIPI DC (4-lane DPHY v2.0 or 3-lane CPHY V1.1) 1 × DVP camera (up to 150MHz input data) * Supports multi-channel 8K video output and 4K video input, up to seven-screen output with different displays
Audio
2 × 8-channel I2S 2 × 2-channel I2S 2 × SPDIF 2 × 8-channel PDM (supports multi-MIC array) 1 × Dual-channel digital audio codec (16-bit DAC) 1 × VAD
Os
Android: Android 12.0 Linux: Ubuntu Desktop, Ubuntu Server, Debian11, Buildroot, RTLinux, Kylin Linux, UOS * Supports UEFI Boot
Dimension
82 mm × 53 mm
Environment
Operating Temperature: -20℃-60℃, Storage Temperature: -20℃-70℃, Storage Humidity: 10%-80%
Network
Integrated with PCIe3.0/GMAC/SDIO3.0/USB3.0, it can be extended to multi-channel Gigabit Ethernet WiFi 6/Bluetooth, 5G/4G LTE
Interface type
MXM3.0 (314 PIN, 0.5mm pitch)
Other interface
9 × I2C 10 × UART 5 × SPI 7 × ADC 16 × PWM 1 × SDMMC GPIO
Usb
USB3.1(Gen1) OTG × 2 USB3.1(Gen1) HOST × 1 USB2.0 HOST × 4 USB2.0 OTG × 2
