• Firefly AIO-3588Q 8K AI ARM Motherboard
  • Firefly AIO-3588Q — view 2
  • Firefly AIO-3588Q — view 3
  • Firefly AIO-3588Q — view 4
  • Firefly AIO-3588Q — view 5
1 5

Firefly

AIO-3588Q 8K AI ARM Motherboard

AIO-3588Q 8K AI ARM Motherboard

$419.00 USD
$419.00 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

AIO-3588Q 8K AI ARM Motherboard is a Firefly product sold by Ai-Paipai. Key specifications — Soc: RK3588 Up to 2.4GHz · Npu: Up to 6TOPs(INT8) Support INT4/INT8/INT16 mixed… · Ram: LPDDR4/LPDDR4x/LPDDR5 (4GB/8GB/16GB, up to 32GB) · Storage: eMMC (16GB/32GB/64GB/128GB optional) · Wireless network: 2.4GHz/5GHz dual-band WiFi 6 (802.11a/b/g/n/ac/ax),…. Typical applications: edge AI inference, machine vision and IoT gateway deployments. Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.) is an authorized distributor providing local technical support, pre-installed SDK / OS images, OEM / ODM customization, and worldwide shipping.

✅ Authorized Distributor — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)

This product is supplied by an authorized distributor of the original brand. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.

AIO-3588Q has rich interfaces, including Gigabit Ethernet, WiFi 6, 5G/4G expansion, rich video input and output interfaces, and M.2 SATA SSD. It can be widely used in ARM PC, edge computing, cloud terminals, cloud servers, industrial control, smart vehicles and other fields.

Feature

  • New-gen AIoT SoC: RK3588 Series: RK3588 is Rockchip's new generation flagship AIoT chip, using 8nm lithography technology.
  • 6 TOPS Powerful Computing Power: Equipped with a powerful NPU with 6 TOPS computing power, it supports INT4/INT8/INT16 mixed operations and TensorFlow/MXNet/PyTorch/Caffe framework switching. Its good compatibility can meet the edge computing needs of terminal devices.
  • 8K Experience: The motherboard supports 8K@60fps H.265/VP9 video decoding, bringing true 8K high-definition display and exquisite picture quality. It is fully compatible with OpenGL ES 1.1, 2.0, 3.2, OpenGL ES 2.2, and Vulkan 1.2. The 2D hardware engine significantly improves display performance, bringing a smoother operating experience and meeting users' diverse viewing needs.
  • Multi-channel Input and Output: The motherboard has HDMI RX2.0/MIPI-CSI/DP1.4/8T1120 multi-channel video output and HDMI RX2.0/MIPI-CSI/DP1.4 video input interface, supports multi-channel 8K video output and 4K video input, can achieve up to seven-screen display, provides up to 16-channel 1080P@30fps cameras, and 4, 6, and 8-channel wide-angle seamless stitching.
  • Super-large 32GB RAM: The motherboard can be configured up to 32GB, breaking through previous memory limitations, bringing faster response speeds, and meeting product demands for large memory and high storage capacity.
  • M.2 SATA3.0 /PCIe SSD Expansion: M.2 SATA3.0/PCIe NVMe SSD (2242) allows easy expansion of devices to TB storage capacity.
  • PCIe 3.0 for High-speed Transmission: Onboard standard PCIe 3.0 (4 Lane) interface, extremely fast and stable transmission speed, can connect to standard PCIe 3.0 devices.

Feature

  • ARM PC
  • Edge Computing
  • Industrial Control
  • Cloud Servers
  • Cloud Terminals
  • Smart Vehicles

Shipping list

  • Main unit × 1
  • Power adapter / cable (region plug on request) × 1
  • Accessories vary by configuration — contact us for the exact included list.
Shipping list
AIO-3588Q x 1 12V 2A power adapter x 1 Copper tube antenna x 3 Connection cable (FC10 to DB9 serial port cable) x 4 HDMI-2.1-8K data cable x1 Radiator x 1
Soc
RK3588 Up to 2.4GHz
Gpu
ARM Mali-G610 MP4 quad-core GPU Support OpenGL ES3.2/OpenCL 2.2/Vulkan1.1, 450 GFLOPS
Npu
Up to 6TOPs(INT8) Support INT4/INT8/INT16 mixed operations Support framework switching of TensorFlow / MXNet / PyTorch / Caffe
Vpu
Decoding: 8K@60fps H.265/VP9/AVS2, 8K@30fps H.264 AVC/MVC, 4K@60fps AV1, 1080P@60fps MPEG-2/-1/VC-1/VP8 Encoding: 8K@30fps H.265 / H.264
Ram
LPDDR4/LPDDR4x/LPDDR5 (4GB/8GB/16GB, up to 32GB)
Storage
eMMC (16GB/32GB/64GB/128GB optional)
Storage expansion
1 × M.2 SATA 3.0 SSD (2242), 1 × TF Card
Pcie
1 x PCIe 3.0 (4 lanes)
Sata
1 x M.2 SATA 3.0
Power
12V (voltage tolerance ± 5%)
Power consumption
Min: ≈0.78W(12.0V/65mA) Normal: ≈2.3W(12.0V/190mA) Max: ≈14.4W(12.0V/1200mA)
Video output
1 × HDMI2.1 (8K@60fps or 4K@120fps) 1 × DP1.4 (8K@30fps, via USB-C) 1 × VGA (1080P@60fps) 1 × eDP1.3 (2K@60Hz) 2 × MIPI-DSI (4K@60fps) Support six-screen different display
Video input
1 × HDMI-IN (4K@60fps), support HDCP 2.3 1 × MIPI_CSI0 (1×4 lanes or 2 × 2 lanes, 30P-0.5mm) 1 × BTB (1×MIPI_CSI1 (4 lanes) or 2×MIPI_CSI1 (2 lanes) + 2×MIPI_D/C (4 lanes DPHY v2.0 or 3-lane CPHY V1.1)
Os
Android and Linux OS Support Kernel-based Virtual Machine (KVM) and Docker container technology You can simultaneously run Android, Ubuntu, Debian, and Linux and achieve a “One Screen for One OS” display.
Dimension
146 mm x 102 mm x 37.5 mm
Environment
Operating temperature: -20℃~60℃ Operating humidity: 10%~90%RH (non-condensing)
Wireless network
2.4GHz/5GHz dual-band WiFi 6 (802.11a/b/g/n/ac/ax), Bluetooth 5.0, scalable 5G/4G LTE
Ethernet
2 × 1000Mbps Ethernet (RJ45)
Usb
4 × USB 3.1 (Gen1) 3 × USB 2.0 (pin) 1 × USB-C (OTG/DP1.4)
Other
2 x RS232 1 x RS485 1 x CAN 1 x Debug 1 x 20P-2.0 pin (GPIO, ADC, SPI, I2C, LED\REV\PWR\RST) 1 x CAN (not supported by AIO-3588MQ)
Product tutorials
Click Here
Sdk software and firmware files
Click Here
Product tutorialsClick Here
Product datasheetClick Here
SDK software and firmware filesClick Here

Document links will be replaced with the official Firefly resource URLs on request.

Our cooperating carriers: FedEx, DHL, UPS, SF Express

Delivery Area And Cost

Country/Region 0–2kg 2–3kg 3–4kg 4–5kg 5–6kg 6–7kg 7–8kg 8–9kg 9–10kg
Japan, Taiwan, Hong Kong, Macau $15 $20 $25 $30 $35 $40 $45 $50 $55
Singapore, Thailand, Malaysia $20 $25 $30 $35 $40 $45 $50 $55 $60
Indonesia, Philippines $25 $30 $40 $50 $60 $70 $80 $85 $95
South Korea $25 $35 $35 $45 $45 $55 $55 $65 $65
United States, Australia, New Zealand, Canada, UK, and most of Western Europe $30 $45 $55 $65 $75 $85 $95 $105 $115
Other regions (Eastern Europe, Middle East, Latin America, etc.) $50 $65 $80 $95 $110 $125 $135 $150 $165

Shipping time is for reference only; the actual situation shall prevail.

Why Buy From Ai-Paipai?
  • Authorized & Genuine — sourced directly from brand-approved channels.
  • Local Engineering Support — datasheets, SDKs, and pre-flashed images in English and Chinese.
  • OEM / ODM & FPGA Customization — tailor specs, enclosures, and BSP for your project.
  • One-Stop Sourcing — Firefly + youyeetoo + our own FPGA / edge lineup in one store.
View full details

Frequently asked questions

What is AIO-3588Q 8K AI ARM Motherboard used for?
AIO-3588Q 8K AI ARM Motherboard is a Motherboard / SBC from Firefly. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.

Does AIO-3588Q 8K AI ARM Motherboard include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item as an authorized distributor and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.

Can I order AIO-3588Q 8K AI ARM Motherboard with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.

How is AIO-3588Q 8K AI ARM Motherboard shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.

Specifications

Product Datasheet Click Here
Product Wiki Click Here
New-gen AIoT SoC RK3588 Series: RK3588 is Rockchip's new generation flagship AIoT chip, using 8nm lithography technology.
6 TOPS Powerful Computing Power Equipped with a powerful NPU with 6 TOPS computing power, it supports INT4/INT8/INT16 mixed operations and TensorFlow/MXNet/PyTorch/Caffe framework switching. Its good compatibility can meet the edge computing needs of terminal devices.
Super-large 32GB RAM The motherboard can be configured up to 32GB, breaking through previous memory limitations, bringing faster response speeds, and meeting product demands for large memory and high storage capacity.
M.2 SATA3.0 /PCIe SSD Expansion M.2 SATA3.0/PCIe NVMe SSD (2242) allows easy expansion of devices to TB storage capacity.
PCIe 3.0 for High-speed Transmission Onboard standard PCIe 3.0 (4 Lane) interface, extremely fast and stable transmission speed, can connect to standard PCIe 3.0 devices.
