Firefly

AIO-3576C ARM AIOT Industrial Edge Motherboard

AIO-3576C ARM AIOT Industrial Edge Motherboard

$269.00 USD
$269.00 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

AIO-3576C ARM AIOT Industrial Edge Motherboard is a Firefly product sold by Ai-Paipai. Key specifications — Soc: Rockchip RK3576 · Ai performance: Support the privatization deployment of… · Ram: LPDDR5 (4GB/8GB/16GB Optional) · Storage: eMMC (16GB/32GB/64GB/128GB/256GB Optional) · Video input: 2 × MIPI-CSI DPHY (1×4Lanes or 2×2Lanes, 30Pin-0.5mm) 1…. Typical applications: edge AI inference, machine vision and IoT gateway deployments. Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.) is an authorized distributor providing local technical support, pre-installed SDK / OS images, OEM / ODM customization, and worldwide shipping.

✅ Authorized Distributor — Ai-Paipai (Shenzhen AiPaipai Intelligent Technology Co., Ltd.)

This product is supplied by an authorized distributor of the original brand. We provide local technical support, pre-installed SDK / mirror images, and OEM / ODM customization, plus fast global shipping.

The AIO-3576C industrial motherboard is a high-performance computing solution designed for AI and multimedia applications, featuring 6 TOPS of NPU computing power for efficient AI inference and edge computing. It supports the private deployment of large-scale AI models, enabling secure and localized processing without cloud dependency. With triple independent display outputs, it delivers flexible multi-screen configurations for digital signage, control systems, and interactive kiosks. Additionally, it provides robust 4K video encoding and decoding capabilities, ensuring smooth ultra-high-definition media processing for applications like video analytics, surveillance, and multimedia broadcasting.

Feature

  • Next-Generation AIoT Chip RK3576: The chip is equipped with Rockchip RK3576, adopts big.LITTLE architecture (4×A72 + 4×A53), uses advanced process technology, and has a main frequency of up to 2.2GHz, providing strong support for high-performance computing and multi-tasking. It is equipped with Mali-G52 MC3 GPU, providing 145G FLOPS performance, which can achieve efficient heterogeneous computing and meet the needs of graphics-intensive applications.
  • 6 TOPS Computing Power, Supports YOLO Algorithm: The 6 TOPS NPU supports INT4/INT8/INT16/FP16/BF16/TF32 operations with dual-core collaborative/independent execution, enabling multi-task parallelism across diverse scenarios. It accelerates YOLO-based real-time object detection, delivering faster, more accurate multi-object recognition for AI applications.
  • Triple Independent Displays: It supports multiple display interfaces such as HDMI, MIPI DSI, LVDS, etc., and realizes three independent displays with 4K@120Hz ultra-clear resolution to meet the diverse display needs of various scenarios.
  • Meets Industrial Application Requirements: The AIO-3576C integrates industrial-grade features including real-time networking, Flexbus, hardware isolation, and DSMC, coupled with RTLinux kernel support for superior real-time performance, making it ideal for diverse industrial applications.

Hardware Overview

Shipping list

  • Main unit × 1
  • Power adapter / cable (region plug on request) × 1
  • Accessories vary by configuration — contact us for the exact included list.
Ai performance
Support the privatization deployment of ultra-large-scale parametric models under the Transformer architecture, such as the Gemma, ChatGLM, Qwen, Phi, and other large language models. It supports traditional network architectures such as CNN, RNN, and LSTM, and supports the import and export of RKNN models; Support a variety of deep learning frameworks, including TensorFlow, TensorFlow Lite, PyTorch, Caffe, ONNX, and Darknet. It also supports the development of custom operators. Support Docker container management technology. It supports the real-time object detection algorithm YOLO (You Only Look Once), which is faster and more real-time compared with traditional object detection methods, and can accurately identify and locate multiple target objects in images or videos, powering AI applications.
Soc
Rockchip RK3576
Cpu
Octa-core 64-bit processor (4×A72 + 4×A53), up to 2.2GHz
Gpu
G52 MC3 @ 1GHz, supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, embedded high-performance 2D acceleration hardware
Npu
6 TOPS computing power NPU, support INT4/INT8/INT16/FP16/BF16/TF32 operation, support dual-core collaborative or independent work, support multi-task, multi-scenario parallelism.
Vpu
Decode: 8K@30fps/4K@120fps (H.265/HEVC, VP9, AVS2, AV1), 4K@60fps (H.264/AVC) Encode: 4K@60fps (H.265/HEVC, H.264/AVC)
Ram
LPDDR5 (4GB/8GB/16GB Optional)
Storage
eMMC (16GB/32GB/64GB/128GB/256GB Optional)
Power
DC 12V (5.5mm × 2.1mm, support 12V~24V wide voltage input), 1 × DC_IN (4Pin-2.54mm)
Power consumption
Max: 8.4W(12V/700mA), Normal: 1.2W(12V/100mA), Min: 0.24W(12V/20mA)
Video input
2 × MIPI-CSI DPHY (1×4Lanes or 2×2Lanes, 30Pin-0.5mm) 1 × MIPI-CSI D/CPHY (DPHY(1×4 Lanes/2×2 Lanes) or CPHY(3Lanes), 30Pin-0.5mm)
Audio
1 × MIC (2Pin-2mm), 1 × SPK (4Pin-2mm, 2×10W/6Ω or 2×10W/8Ω), 1 × 3.5mm Audio jack (Support MIC recording, American Standard CTIA)
Os
It supports the RTLinux kernel and has excellent real-time performance, which is widely used in industrial application scenarios. Support Android14, Linux OS, Buildroot, and domestic operating systems, providing a safe and stable system environment for product research and production. It has new industrial features such as a real-time network, Flexbus, hardware resource isolation, and DSMC to meet the needs of different industrial applications.
Dimension
126.0 mm × 94.4mm × 14.2mm
Weight
≈91g
Environment
Operating Temperature: -20℃ ~ 60℃ Storage Temperature: -20℃ ~ 70℃ Storage Humidity: 10%~90%RH (non-condensing)
Other interface
1 × RS232 (3Pin-2mm), 1 × RS485 (3Pin-2mm), 1 × CAN (3Pin-2mm), 1 × I2C (4Pin-2mm), 4 × ADC (6Pin-2mm), 1 × Debug (3Pin-2mm), 1 × LCD_PWR (6Pin-2mm), 1 × TP_I2C (6Pin-2mm), 1 × FAN (4Pin-1.25mm), 1 × Screen voltage jumper (Single-row pin headers, 6Pin-2mm)
Button
1 × Reset, 1 × Recovery, 1 × BOOT
Product tutorials
Click Here
Sdk software and firmware files
Click Here
Product tutorialsClick Here
Product datasheetClick Here
SDK software and firmware filesClick Here

Document links will be replaced with the official Firefly resource URLs on request.

Our cooperating carriers: FedEx, DHL, UPS, SF Express

Delivery Area And Cost

Country/Region 0–2kg 2–3kg 3–4kg 4–5kg 5–6kg 6–7kg 7–8kg 8–9kg 9–10kg
Japan, Taiwan, Hong Kong, Macau $15 $20 $25 $30 $35 $40 $45 $50 $55
Singapore, Thailand, Malaysia $20 $25 $30 $35 $40 $45 $50 $55 $60
Indonesia, Philippines $25 $30 $40 $50 $60 $70 $80 $85 $95
South Korea $25 $35 $35 $45 $45 $55 $55 $65 $65
United States, Australia, New Zealand, Canada, UK, and most of Western Europe $30 $45 $55 $65 $75 $85 $95 $105 $115
Other regions (Eastern Europe, Middle East, Latin America, etc.) $50 $65 $80 $95 $110 $125 $135 $150 $165

Shipping time is for reference only; the actual situation shall prevail.

Why Buy From Ai-Paipai?
  • Authorized & Genuine — sourced directly from brand-approved channels.
  • Local Engineering Support — datasheets, SDKs, and pre-flashed images in English and Chinese.
  • OEM / ODM & FPGA Customization — tailor specs, enclosures, and BSP for your project.
  • One-Stop Sourcing — Firefly + youyeetoo + our own FPGA / edge lineup in one store.
View full details

Frequently asked questions

What is AIO-3576C ARM AIOT Industrial Edge Motherboard used for?
AIO-3576C ARM AIOT Industrial Edge Motherboard is a Motherboard / SBC from Firefly. It is typically used in embedded computing, edge AI inference, industrial control and rapid prototyping, and can be integrated into custom carrier boards or finished devices.

Does AIO-3576C ARM AIOT Industrial Edge Motherboard include technical support, datasheets or pre-flashed images?
Yes. Ai-Paipai supplies this item as an authorized distributor and provides local engineering support, datasheets, SDKs and pre-flashed system images where applicable, plus OEM / ODM customization for volume projects.

Can I order AIO-3576C ARM AIOT Industrial Edge Motherboard with OEM / ODM options or CE / FCC / RoHS certification?
OEM / ODM customization (specs, enclosure, BSP) is available, and CE / FCC / RoHS certified options can be provided on request for EU and US imports. Contact us for a quote.

How is AIO-3576C ARM AIOT Industrial Edge Motherboard shipped, and what is the lead time?
Orders ship worldwide from Shenzhen. Stock items typically dispatch within a few business days; configurable or made-to-order variants take longer. Exact lead time is shown at checkout or on request.

Specifications

Product Datasheet Click Here
Product Wiki Click Here
Triple Independent Displays It supports multiple display interfaces such as HDMI, MIPI DSI, LVDS, etc., and realizes three independent displays with 4K@120Hz ultra-clear resolution to meet the diverse display needs of various scenarios.
Meets Industrial Application Requirements The AIO-3576C integrates industrial-grade features including real-time networking, Flexbus, hardware isolation, and DSMC, coupled with RTLinux kernel support for superior real-time performance, making it ideal for diverse industrial applications.
